RediPave Traffic Islands
A modern approach to traffic and pedestrian refuge Islands manufactured in recycled rubber. Available in various widths and lengths to suit applications such as pedestrian crossings, buildouts, chicanes, road closures, RediPave Traffic Islands offer durability, strength, no excavation, no spoil. Now available with an unique Adhesive option for depth restraints such as bridges
Kerbing & Traffic Islands
RediPave Traffic Islands
RediPave Traffic Islands offer an alternative to traditional materials, by creating a modular design which not only offers flexibility, but also offers various widths and lengths to suit applications. Using Rediweld’s unique anchor block connector, these Islands offer durability and strength by the energy absorption which minimises any potential damage to the side walls of a tyre that can lead to a puncture.
We offer the RediPave Traffic Islands with or without the Hi-Viz white reflective marking which are moulded into the products at time of manufacture; this adds additional visibility.
They are surface mounted, installation is quick with minimal interruption to road users, and are made from recycled materials in the UK.
RediPave Traffic Islands can be used in conjunction with any lighted column, Posts, bollards and signs and are available in colour Black or 'Granite' Grey.
Product meets DfT specifications. Made from recycled rubber in the UK.
RediPave Traffic Islands
Key Features
-
Complete System
- Manually handled with no infill required and relocatable
-
Easy Installation
- Installed in less than one hour reducing risk to operatives
-
Minimum Disruption
- To users and the public
-
Surface Mounted
- Bolt down with no excavation and no spoil
-
Environment
- Recycled product made in the UK
RediPave Traffic Islands
Technical Information
| Module |
Height (mm) |
Length (mm) |
Width (mm) |
Weight (kg) |
| 1. Splitter End | 125 | 250 | 500 | 14.0 |
| 2. Splitter Middle | 125 | 500 | 500 | 21.7 |
| 3. RediPave Corner | 125 | 500 | 500 | 21.9 |
| 4. RediPave Edge | 125 | 500 | 500 | 21.7 |
| 5. RediPave Radius | 125 | 500 | 500 | 14.0 |
| 6. RediPave Centre | 125 | 500 | 500 | 21.5 |
| 7. RediPave Left Side | 125 | 600 | 500 | 16.0 |
| 8. RediPave Bull Nose | 125 | 350 | 700 | 14.0 |
| 9. RediPave Right Side | 125 | 600 | 500 | 16.0 |
| New Modules | Height (mm) | Length (mm) | Width (mm) | Weight (kg) |
| 200mm RediPave Edge | 125 | 500 | 200 | 8.80 |
| 200mm RediPave Centre | 125 | 500 | 200 | 8.80 |
**Rediweld can produce PDF's to suit your schemes**
**CAD drawings on request**
Frequently asked questions
Can’t find the answer you’re looking for? Reach out to our customer support team
How long does it take to install a standard 1.5m x 1.5m RediPave Island?
Due to the ease of installation, you can easily install a 1.5m x 1.5m Island in around 45 minutes to 1 hour depending on experience.
How long does it take to install a complete pedestrian crossing Island 1.5x x 1.5m?
You can install a complete Pedestrian Crossing Island in less than 2 hours, this includes the 2 x RediPave Islands, 2 x Keep left Bollards and our RediFix bolt down tactiles, it also offers a huge cost saving in comparison to Traditional Islands in the overall cost and installation method.
Is there a minimum road width that the Island should be installed on?
The width of a RediPave Island will depend on the vehicles using the junction, tracking software would be used to establish the types of vehicles that use that junction and to show turning manoeuvres to avoid risk of vehicles hitting the Island.
On normal routes, the road width would be taken into consideration, along with vehicle speeds and usage to establish the size of a Pedestrian Island or refuge that would be required along the highway.
